The SE 740 optical dissolved oxygen sensor delivers reliable in-line measurements in standard industrial and hygienic applications.
Measuring range: | 4 ppb / 0.05 … 300 % saturation |
Resolution: | 0.1 ppb |
Response time at 25 °C (air –> N2): | 98 % full scale < 30 s |
Pressure range | Max. 174 psi (12 bar) |
Temperature range: | 14 … 266 °F (–10 … 130 °C) measurements: 32 … 176 °F (0 … 80 °C) |
O-ring material: | Silicon and FKM (Viton) |
Process-wetted sensor parts: | Stainless steel 1.4435 |
Temperature detector: | NTC 22 kohms |
Process adaptation: | Pg 13.5 |
Sensor cap: | M12 (8 pins) |
Title | Type | |
---|---|---|
SE 740 Spec Sheet | Technical Specifications | DOWNLOAD |
DOWNLOAD | ||
Oxygen Sensor Selection Guide | Selection Guide | DOWNLOAD |
DOWNLOAD | ||
SE 740 Manual | Manual | DOWNLOAD |
DOWNLOAD | ||
Sensor Application Data Sheet | Application Data Sheet | DOWNLOAD |
DOWNLOAD |
Don’t be limited by your equipment, start using pain-free instrumentation & keep production moving.
